Product Description

 CE,FCC Certification!Two Years' Warranty!New Design!

Digital Gold and Silver Tester , Digital Gold Purity Analyzer , Gold Testing Machine Factory

Application:pawnbroking,jewelry industry,banking industry,jewelry testing center,mining industry,precious metal recycling,precious metal materials researching laboratory.,etc.



These series instrument is the dramatic updating and upgrading products.Compared with other competing products,it has been focused on enhancing weighting resolution,simplified operation procedure and operation method,upgraded software application function,improved reliability of measuring result. offer respectively three content measuring model for gold,platinum,silver and one alloy measuring model;



No need to bundle samples.Following value can be displayed precisely and quickly with only two procedure:

(1)karat value,percentage content,density for gold

(2)PT value,percentage content,density for platinum

(3)S value,percentage content,density for silver

(4)percentage content,density for other alloy.



Measuring Type:

Precious metal.such as gold,Karat gold,platinum,silver.

Mixed metal or other alloy metal.

Jewelry materials.such as ring,necklace,bracelet,watchband,belt fastener,gold ingot,gold bar,statue,coin.,etc.

Notes:

Following products can't be tested:

(1).products of which inside is hollow ;

(2).products set with precious stones;

(3).products of which the density is very close to precious metal.



Features:

• Distinguish whether the gold,karat gold,platinum,silver,other precious metal is the genuine or not.
• Test the purity of gold,karat gold,platinum,silver to confirm if the marked content is correct or not.
• No need to cut samples;also it can be measured immediately.
• Can shift to measure Karat and purity percentage of gold-silver -copper,gold-copper,gold-silver respectively.
• Function of density measuring and normal gram scale.
• Either water or alcohol would be as medium.
• Function of setting actual water temperature.
• Adopt completed injection molding PC sink(length:15.3cm X width10.7cm X 9.3cm)
• Including RS-232 interface;It's convenient to connect PC and printer.AU-40 could be optionally availabe to print result.
• Adopt injection moulding windproof dustproof shield;Convenient configuration;Better durability.
• Power supply:AC 100V-240V;50HZ/60HZ(Europe standard)
• Weight/packing size:4.5kg/length 42.5cm X width 17.5cm X height 32.5cm



Measurement Resolution and Range:

• AU-300K weighting resolution:0.005g,minimum weight:4g,density resolution:0.001g/cm3
• AU-600K weighting resolution:0.005g,minimum weight:4g,density resolution:0.001g/cm3
• AU-120K,200K weighting resolution:0.001g,minimum weight:2g,density resolution:0.001g/cm3
• 900K,1200K,2000K,3000K weighting resolution:0.01g;minimum weight:5g;density resolution:0.01g/cm3
• K value range:9k,10k,11k,12k,13k,14k,15k,16k,17k,18k,19k,20k,21k,22k,23k,24k and % percentage content.
• Platinum content range:PT600,PT650,PT700,PT750,PT800,PT850,PT900,PT950,PT1000 and % percentage content.
• Silver content range:S600,S650,S700,S750,S800,S850,S900,S950,S1000 and % percentage content.
• The proportion of copper-silver for gold-silver-copper can be shifted cyclically with 9/1,8/2,7/3,6/4,5/5,4/6,3/7,2/8,1/9.the default setting is 7/3.



Measuring Procedure:

(1)Measure the weight in air firstly,press ENTER button.

(2)Place the sample into water to measure weight in water.Press ENTER button.display result.



Standard Accessories:

(1)Host,(2)Sink,(3)Measuring plate,(4)Tweezers,(5)Thermometer,(6)weight,(7)windproof dustproof cover(8)One set of measuring gold dust accessories(9)Power supply



Specification Table

Brand	Quarrz
Model	AU-300K / AU-600K / AU-900K	AU-120K / AU-200K	AU-1200K / AU-2000K / AU-3000K
Style	Hot and Classic	High-precision	High-capacity
Maximum weight	300g / 600g / 900g	120g / 200g	1200g / 2000g / 3000g
Weight standard deviation	0.005g / 0.005g /0.01g	0.001g	0.01g
Minmum measuring sample Reference weight	4g / 4g / 5g	2g	5g
Density resolution	0.001g/cm3	0.001g/cm3	0.001g/cm3
Sink size	Length15.3 cm×width10.7 cm×height9.3cm		Length20.3 cm×width15.7 cm×height11.3cm
Measuring function	(1)karat value,percentage content,density for gold (2)PT value,percentage content,density for platinum (3)S value,percentage content,density for silver (4)percentage content,density for other alloy.
Gold K value	(9 ,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24)K  &content percentage %
Platinum	PT600 ,PT650,PT700,PT750,PT800,PT850,PT900,PT950,PT1000  & content percentage %
Silver	S600 ,S650,S700,S750,S800,S850,S900,S950,S1000  & content %
Measuring principle	Archimedes buoyancy method
Measuring time	About 5 to 20 seconds
Measuring procedure	(1)Measure the weight in air firstly,press ENTER button. (2)Place the sample into water to measure weight in water.Press ENTER button.display result.
Parameter setting	Water temperature setting,measuring medium density setting,air density setting,main materials and secondary materials density setting,copper-silver proportion setting
Copper-silver proportion range	can be shifted cyclically with 9/1,8/2,7/3,6/4,5/5,4/6,3/7,2/8,1/9.the default setting is 7/3.
Calibration method	Single button calibration,automatic testing
Standard accessories	(1)Host,(2)Sink,(3)Measuring plate,(4)Tweezers,(5)Thermometer,(6)weight,(7)windproof dustproof cover(8)One set of measuring gold dust accessories(9)Power supply
Data interface	Standard RS-232 interface
Optional accessories	AU-40 printer,AU-40A data connecting line
Power supply	AC100V~240V  50HZ/60HZ   Europe standard
Gross weight/size	4.3kg/ Length 42.5 cm× width 17.5 cm×height 32.5cm (no including weights)
