High Speed High Precision Conveyor Belt Weighing Sorter Checkweigher Check Weigher Weighing Sorting Machine
High Speed High Precision Conveyor Belt Weighing Sorter Checkweigher Check Weigher Weighing Sorting Machine
Regular price
£19,942.17 GBP
Regular price
£0.00 GBP
Sale price
£19,942.17 GBP
Taxes included.
Quantity
Couldn't load pickup availability
Mchine characteristics
The weight sorting machine can screen products of different weight ranges to different production lines, and can comprehensively display production data such as production quantity, batch tracking, total weight, effective weight, and excluding sorting weight, which can replace manual weighing.
Machine Features
* Built-in production record, which can record the quantity, weight and ratio of each grade in detail;
* Use high-density self-lubricating injection molding material and double-contact design to double the wear resistance coefficient and service life;
* 304 stainless steel material, resistant to corrosion and not easy to rust;
* Chinese and English bilingual self-contained tutorial mode is convenient for learning and operation.
* Use high-density self-lubricating injection molding material and double-contact design to double the wear resistance coefficient and service life;
* 304 stainless steel material, resistant to corrosion and not easy to rust;
* Chinese and English bilingual self-contained tutorial mode is convenient for learning and operation.
Product Description
Specification
|
Technical Data Sheet
|
||||||
|
Model
|
CQ-FX series
|
Air pressure interface
|
Φ8mm
|
|||
|
Power
|
AC220V±10% 50HZ（60HZ）
|
Preset product number
|
100 pcs
|
|||
|
Rated power
|
0.3KW
|
Operation direction
|
Facing machine ,from left to right
|
|||
|
Weighing range
|
customize
|
Reject method
|
Swing, air blow, pusher, belt sink, etc.
|
|||
|
External air source
|
0.6-1Mpa
|
Control system
|
High-speed A/D sampling controller
|
|||
|
Working environment
|
Temperature: 0℃～40℃, Humidity: 30%～95%
|
Material
|
304 stainless steel
|
|||
|
Model
|
CQ-FX series
|
||||||
|
weighting grading
|
3-16level or custom
|
||||||
|
weighing range
|
20g-15g
|
||||||
|
highest check accuracy
|
±3g
|
||||||
|
minimum scale
|
0.1g
|
||||||
|
maximum speed
|
100-300package/minute
|
||||||
|
weigh material size
|
L400mm*W220mm
|
||||||
|
dimensions
|
L2140mm*W1110mm*H1231mm
|
||||||
|
rejection device
|
blow 、push、swing arm
|
||||||
|
woek power
|
AC 220V±10% 50-60Hz
|
||||||
|
weight
|
about 280KG
|
||||||
