Flat pack container house

Size:2990*6055*2896mm

No.

Name

Info

1

Top Frame

Beam:

2 pcs of 5530*2.0

2 pcs of 2138*2.0

4 pcs of 210*150

Purlins 80*40*1.2

18 sqm of Glasswool18 sqm

Bake painted steel palted 0.45mm

2

Bottom Frame

Beam:2 pcs of 5530*2.0
Beam:2pcs 2138*2.0
Corner connector: 4 pcs of210*150
Purlines 9 pcs of 100*50*1.2*9

3

Column

 4 pcs 2.0mm 210*150*2526

4

Bottom Accessories

 50 S sink

5

Floor

 5 pcs of 18mm cement fiber board

6

PVC floor

 1.6mm PVC floor

7

Door

 steel door 970*1970

8

Window

 PVC single layer glass sliding window 930*1200*2

9

Wall Panel

  steel rockwool sandwich panel  V950 0.3mm/50(50kg/m³)

10

Pipe

 4 pcs of 50PVC  2750-4

11

Ceiling

 831 type ceiling

12

Corner trimming

 4 pcs of corner trimming

13

Accessories

 1 set of bolts and glue

14

Accessories

 Skirting line

15

Electronical system

 1 pc of 3-hole socket ,3 pcs of 5-hole sockets, 1 switch distribution box,  1 industrial socket, wire, 36W strip light *2 (power distribution is done on the inner corner of the inner wall)
